Black Bandit Race Exhaust Copy of GM Duramax L5P 4" Down-pipe Back Race Exhaust 2017-2023

6.6L Duramax LB7 LLY LBZ 5" Downpipe Back Straight Pipe Exhaust System | 2001-2007

4" Downpipe-Back

409 Stainless Steel

$440.00
$797.50 $440.00
Sale 45% Sold out
  • Black Bandit Race Exhaust Copy of GM Duramax L5P 4" Down-pipe Back Race Exhaust 2017-2023
  • Black Bandit Race Exhaust GM Duramax 6.6L Down-pipe Back Race Exhaust (2001-2007)
1 2
GM Duramax LB7, LLY, LBZ, 6.6L (2001 - 2007)

6.6L Duramax LB7 LLY LBZ 5" Downpipe Back Straight Pipe Exhaust System | 2001-2007

6.6L Duramax LB7 LLY LBZ 5" Downpipe Back Straight Pipe Exhaust System | 2001-2007

1,723 Google Reviews

SKU:ESSS-GM-01-4

$440.00
$797.50 $440.00
Sale 45% Sold out
Size
Exhaust Quality

Select your vehicle

Choose your vehicle to confirm this product fits your truck

View full details

Overview

The Duramax LB7 LLY LBZ race exhaust is a downpipe-back system for 2001–2007 Chevrolet Silverado and GMC Sierra HD trucks with the 6.6L Duramax LB7, LLY, or LBZ engine. It replaces the factory exhaust system after the turbo downpipe with a straight pipe setup to improve exhaust flow and reduce backpressure.

The system is available in two sizes: 4-inch and 5-inch. The 5-inch version is offered in either T-304 or T-409 stainless steel. These systems are commonly used on modified Duramax trucks where increased exhaust flow is needed.

This setup is typically installed as an LB7 exhaust upgrade or a 5-inch LBZ exhaust system for trucks running performance tuning or other engine modifications.

Compatibility

  • Years: 2001–2007
  • Makes: Chevrolet, GMC
  • Models: Silverado 2500HD, Silverado 3500HD, Sierra 2500HD, Sierra 3500HD
  • Engine: 6.6L Duramax Diesel (LB7, LLY, LBZ)
  • Body: Pickup

Important: Does not fit Cab & Chassis trucks. Check wheelbase, bed length and spare tire clearance before installing.

Technical Specifications

Specification Detail
System Type Downpipe-Back Race Exhaust
Pipe Diameter 4-inch or 5-inch
Material 4-inch system: T-409 Stainless Steel
5-inch system: T-304 or T-409 Stainless Steel
Configuration Straight Pipe (No Muffler)
Exit Style Single-Side Exit
Mounting Hardware Band clamps and exhaust hangers included
Sensor Ports None – race exhaust configuration

Key Features & Build Details

  • 4-Inch or 5-Inch Mandrel-Bent Tubing – Keeps consistent internal diameter through bends to maintain exhaust flow.
  • Downpipe-Back Layout – Replaces the factory exhaust system from the turbo downpipe rearward while keeping the stock routing and hanger locations.
  • Straight Pipe Configuration – No muffler or restriction in the system. Designed for race or off-road builds.
  • Factory Hanger Locations – Built to line up with the stock mounting points on Silverado and Sierra HD trucks.
  • Hardware Included – Band clamps and hangers are supplied for installation.

Performance Benefits

  • Reduced Backpressure – Larger 4-inch or 5-inch tubing allows exhaust gases to exit faster than the factory exhaust system.
  • Lower Exhaust Gas Temperatures – Higher exhaust flow can help control EGT under load.
  • Faster Turbo Response – Reduced restriction helps the turbo spool more efficiently.
  • Supports Modified Duramax Trucks – Common on trucks running tuning or other performance upgrades.

Installation Notes

Moderate installation difficulty. The system installs using the factory exhaust hanger locations and the included band clamps. Basic hand tools are usually enough, but older exhaust hardware may need to be cut or removed.

Tuning may be required after installation depending on the truck setup to prevent diagnostic codes and ensure the engine runs correctly.

Frequently Asked Questions

Will this 2006 LBZ Duramax exhaust fit my truck?

Yes. This exhaust fits 2001–2007 GM 2500HD and 3500HD pickup trucks with the 6.6L Duramax engine, including the 2006 LBZ model. Always confirm your truck’s engine and configuration before ordering.

Is this considered an LB7 exhaust upgrade?

Yes. The system fits 2001–2004 LB7 trucks and is commonly used as a larger diameter exhaust upgrade to improve exhaust flow.

Does this system include a muffler?

No. This is a straight pipe race exhaust with no muffler.

Will this exhaust fit Cab & Chassis trucks?

No. It only fits Silverado and Sierra pickup trucks. Cab & Chassis models use a different exhaust layout.

Is tuning required after installing this exhaust?

Depending on the truck setup, tuning may be needed to avoid check engine lights and to run the engine correctly.

Customer Reviews

Overall rating: 4.3 / 5 from 18 reviews.

No way I could install this in my garage. First, the coupler that goes into the down pipe was welded at the wrong angle which made the exhaust pipe hit the floor of the truck. An exhaust shop had to chop and weld that at a different angle so it would go between the cross member and floor. Just about all hangers had to be cut and welded, other bends were wrong which required cutting and rotating the pipe and welding, then the exit of the pipe was pointing forward on the truck instead of out the side as intended. It took cutting, rotating, and welding that 5" pipe to fix that issue as well. In the end, we used two of the band clamps for ease of removal in the future if needed. I highly recommend not purchasing this kit unless you intend on taking it to a competent exhaust fabricator. It will not work for you and will cost you more money. Also, exhaust shops can't bend 5", only the pipe manufacturers have that tooling, so don't expect them to straighten out the messed up bends.....cut and weld fixes only. It does sound nice, but 5" pipe is 5" pipe. Find a better fitting kit.

Ryan N. 2/5 Verified

6.6L Duramax LB7 LLY LBZ 5" Downpipe Back Straight Pipe Exhaust System | 2001-2007

Product fit well and performs as should only reason I gave it 4 stars and not 5 is some 4in systems I've installed in the past have hangers made onto pipe section and is easier to find where they fit, this kit has hangers made onto the clamps and no instructions on where they should go. However even though it takes a little more time get lined up all the pieces fit very well and we're of good quality and pricing was good as well. Would definitely recommend and buy again.

Kevin H. 4/5 Verified

6.6L Duramax LB7 LLY LBZ 5" Downpipe Back Straight Pipe Exhaust System | 2001-2007

Exhaust is easy to install, took about 30 minutes once I removed the old one. I would give it a five, but my clamps that had the metal rod that goes through the hanger had no rubber isolater. The exhaust can shake out of the hanger. I’d recommend welding together, good quality and sounds amazing.

Luke W. 4/5 Verified

6.6L Duramax LB7 LLY LBZ 5" Downpipe Back Straight Pipe Exhaust System | 2001-2007

Install went very easy. Once original exhaust was out it took approximately 30 mins to install the new. All hangers were in the correct spot and lined up well. 10/10 would recommend. worth the small extra cost since I didnt have to mess with adjustable hangers. 2002 silverado 2500HD CREW CAB.

Taylor O. 5/5 Verified

6.6L Duramax LB7 LLY LBZ 5" Downpipe Back Straight Pipe Exhaust System | 2001-2007
